600 mm Stroke CNC Linear Stage Motion Actuator,X Y Z Axis Linear Slide Rail Cross Sliding Table Linear Rail Guide, SFU1605 Ballscrew with Nema23 Stepper Motor for CNC

★★★★★ 4.7 128 reviews

$90.00
Price when purchased online
Free shipping Free 30-day returns

Sold and shipped by mtbfirstaid.com.au
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$90.00
Price when purchased online
Free shipping Free 30-day returns

How do you want your item?
You get 30 days free! Choose a plan at checkout.
Shipping
Arrives Apr 9
Free
Pickup
Check nearby
Delivery
Not available

Sold and shipped by mtbfirstaid.com.au
Free 30-day returns Details

Product details

Management number 211205036 Release Date 2026/04/04 List Price $36.00 Model Number 211205036
Category
  • 【PACKAGE COMPONENT 】Nema23 stepping motor + step motor support + motor flange + flange + connector + 1605 ball rod + 12mm double track + slide + base. Horizontal load weight 80kg / 176.37 lb; vertical load weight 20kg / 44.09 lb.
  • 【NEMA23 STEPPER MOTOR】Motor size: 57 * 57 * 56mm; torque: 1.26N.m; current: 3A; shaft: single out shaft; voltage: 12-36V (typical value 24V); control mode: pulse control; output speed: 1000 RPM (within 600 RPM).Wiring: Red(A+), Green(A-), Yellow(B+), Blue(B-).
  • 【SFU1605 BALL SCREW】Using bearing steel material,high efficiency and low noise.Effective travel length: 100mm / 3.94inch. Screw precision grade: C7. Screw Pitch: 5mm. Flange nut screw rod with precision up to 0.003mm.
  • 【DOUBLE LINE RAIL SLIDING TABLE DESIGN】HGW12 straight track+HGW12 straight track slide: 12mm double track straight track, the track adopts Gothic structure, the contact Angle is 45°, can achieve the load effect of square using large steel ball, which can improve the load capacity and give full play to the excellent ability of the product. The bottom surface and end surface of the slider guide rail have a fully sealed dust-proof design. After strict processing, the high temperature and low temperature resistance can be up to 80 ℃
  • 【APPLICATION】The CNC Linear Stage Motion Actuator are suitable for production line automation, packaging automation industry, laser cutting equipment, spraying equipment, medical equipment, dispensing solder and 3D printing and other equipment.
  • 【AFTER SALES SERVICE】 If you get stuck, Contact us with any questions that arise. Our customer service team is always ready to assist with any questions you may have.

Item Weight 11.66 pounds
Manufacturer US80HT-S100
Product Dimensions 6.3 x 4.72 x 32.68 inches
